NONUS - Rastreador

Real-time vehicle monitoring and tracking system

Keep your vehicle always on the radar with the N4 Nonus Tracker! With real-time tracking technology, you can track the exact location of your car, motorcycle or fleet directly on your computer screen, on a detailed digital map.

The N4 uses the precision of GPS and the efficiency of GPRS communication, ensuring continuous monitoring, with wide coverage and low cost. Ideal for transportation, logistics and fleet management companies, the N4 Tracker offers greater security, control and efficiency for your business.

Much More Security for Your Vehicle

With the N4 Tracker, you can have more peace of mind in your daily life! Thanks to real-time monitoring, the vehicle's location is recorded in seconds, significantly reducing the risk of theft. Even if the car is in a garage or basement, the last position is stored on the device.

In addition, the N4 is compact and discreet, being installed imperceptibly inside the vehicle. And with GPS accuracy of up to 3 meters, you have total control and security wherever you are!

More protection, more peace of mind, more control!

Features
Basic functions

Operating Voltage:

DC 9v to 90V

Internal Battery:

150mAH

Consumption in Operation:

35mA

Consumption in sleep mode:

8.5mA

Level of Protection:

IP-65

Operating Temperature:

-20°C to +60°C

Temperature Storage:

-20°C to +70°C

Dimensions:

80 x 35 x 17,5mm

weight:

47g

Sensor:

Vibration/Position Sensor

Communication Module:

SIMCOM: A7670SA

Positioning module:

A7670SA / UC6228CI

Faixa de Frequência:

GSM/GPRS/EDGE: 850/900/1800/1900MHZ LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66

GPRS:

Class2,TCP/IP build in GSM Module

Location Accuracy:

3 to 30 meters

Memory (storage):

3,000 positions

Mean Squared Error (RMSE - Root Mean Squares Error):

S degrees

Maximum Output Power:

EGSM900:33dBm±2dB/5dBm±5dB

DCS1800:30dBm±2dB/0dBm±5dB

EGSM900 (8-PSK)：27dBm±3dB/5dBm±5dB

DCS1800 (8-PSK)：26dBm±3dB/0dBm±5dB

LTE-FDD

B1/B2/B3/B4/B5/B7/B8/B28/B66：23dBm±2dB/<-39dBm

Dynamic Output Range:

-15~-108dbm

Reception Sensitivity:

-107dbm

Maximum Frequency Deviation:

±0.1ppm

Sensitivity:

Cold Start: -145 dBm

Warm Start: -156 dBm

Warm Start: -145 dBm

Navigation: -160 dBm

Tracking: -162 dBm

Positioning Mode:

Triple: GPS+BeiDou+LBS

Positioning Time:

Cold boot: on average 32 seconds

GSM antenna:

Internal ✔

GPS antenna:

Internal ✔

LED indicator

On/off and status indicator

Transfer Protocol:

TCP

GPS Data Transmission:

Real-time data/customizable

GPS data:

Real-time location updates

4G network:

Efficient transmission in 1 sec, faster and more accurate

Box:

High mechanical resistance plastic

* Adaptable product for various markets - new configurations and/or technical features can be added or removed at the customer's request.

Time tracking:

✔

Fuel/Power Cutoff (Lockout):

✔

Overspeed Alarm:

✔

Audible Alert for Overspeeding

✔

Power Cut Alarm:

✔

Ignition On Alarm:

✔

Ignition Off Alarm:

✔

Low Battery Alarm:

✔

Vibration alarm:

✔

Jammer Detection Alarm:

✔

Geographic Fence:

✔

Route History:

✔

Fleet Management:

✔

Real-time vehicle monitoring and tracking system

Much More Security for Your Vehicle

Built-in 4G antenna

fast and accurate

location

real-time

route history

Vibration Alarm

fuel cut

Virtual Fence

Excessive Speed Alarm

Speed Alarm

Startup Detection

and Shutdown

Battery Backup

smart

Individual or

Fleet Management
